تفاصيل المنتج:
|
| Material: | Aluminum Alloy | Type: | oil-free |
|---|---|---|---|
| Warranty: | 1 year | Noise Level: | ≤75dB |
| FF Available: | Built-in dry available | Certificates: | CE,ISO |
| Power Source: | Electric | Cooling Method: | Air/Water Cooling |
| إبراز: | ضاغط الهواء المسمار لصناعة المأكولات والمشروبات,ضاغط الهواء ذو المسمار الصفر للتلوث,ضاغط الهواء المسمار 75dB,Zero Contamination Screw Air Compressor,75dB Screw Air Compressor |
||
6. نظام التناضح العكسي
10.غطاء عازل للصوت
| النوع | ضغط العمل | FAD | قوة المحرك | الضوضاء | الوزن ((kg/lbs) | |||||
| بار ((g) | psig | I/s | م3/دقيقة | cfm | كيلوواط | السيارات | dB ((A) | (ب) | FF | |
| المبرد بالماء | ||||||||||
| AQ15VSD A | 4 | 58 | 22-50 | 1.29-301 | 46-106 | 15 | 20 | 67 | 650/1433 | 700/1543 |
| 7 | 102 | 22-46 | 1.34-278 | 47-98 | ||||||
| 10 | 145 | 23-38 | 1.35-229 | 48-81 | ||||||
| 11 | 160 | 23-35 | 1.32-32.10 | 47-74 | ||||||
| 12.75 | 185 | 22-30 | 1.30-181 | 46-64 | ||||||
| AQ18VSDA | 4 | 58 | 22-62 | 1.29-373 | 46-132 | 18 | 25 | 69 | 650/1433 | 700/1543 |
| 7 | 102 | 22-54 | 1.34-322 | 47-114 | ||||||
| 10 | 145 | 23-45 | 1.35-268 | 48-95 | ||||||
| 11 | 160 | 22-42 | 1.32-252 | 47-89 | ||||||
| 12.75 | 185 | 22-37 | 1.30-219 | 46-77 | ||||||
| AQ22VSDA | 4 | 58 | 22-66 | 1.31-395 | 46-139 | 22 | 30 | 70 | 740/1631 | 800/1764 |
| 7 | 102 | 23-66 | 1.35-393 | 48-139 | ||||||
| 10 | 145 | 23-54 | 1.35-325 | 48-115 | ||||||
| 11 | 160 | 22-51 | 1.32-306 | 47-108 | ||||||
| 12.75 | 185 | 22-44 | 1.31-266 | 46-94 | ||||||
| AQ30VSDA | 4 | 58 | 22-83 | 1.31-500 | 46-177 | 30 | 40 | 72 | 740/1631 | 810/1786 |
| 7 | 102 | 23-83 | 1.35-496 | 48-175 | ||||||
| 10 | 145 | 23-77 | 1.35-460 | 48-163 | ||||||
| 11 | 160 | 22-74 | 1.32-444 | 47-157 | ||||||
| 12.75 | 185 | 22-64 | 1.31-385 | 46-136 | ||||||
| AQ37VSDA | 4 | 58 | 42-108 | 2.50-645 | 88-228 | 37 | 50 | 69 | 1300/2866 | 1410/3108 |
| 7 | 102 | 39-105 | 2.35-631 | 83-223 | ||||||
| 10 | 145 | 51-91 | 3.07-5.45 | 108-193 | ||||||
| 11 | 160 | 55-84 | 3.27-503 | 116-178 | ||||||
| 12.75 | 185 | 61-76 | 3.63-4.58 | 128-162 | ||||||
| AQ45VSDA | 4 | 58 | 44-130 | 2.62-7.79 | 93-275 | 45 | 60 | 72 | 1300/2866 | 1410/3108 |
| 7 | 102 | 40-127 | 2.42-7.64 | 86-270 | ||||||
| 10 | 145 | 53-105 | 3.20-628 | 113-222 | ||||||
| 11 | 160 | 57-101 | 3.42-608 | 121-215 | ||||||
| 12.75 | 185 | 66-89 | 3.97-5.33 | 140-188 | ||||||
| AQ55VSDA | 4 | 58 | 44-155 | 2.62-9.31 | 93-329 | 55 | 75 | 75 | 1300/2866 | 1410/3108 |
| 7 | 102 | 40-152 | 2.42-9.10 | 86-321 | ||||||
| 10 | 145 | 53-135 | 3.20-808 | 113-285 | ||||||
| 11 | 160 | 57-127 | 3.42-7.62 | 121-269 | ||||||
| 12.75 | 185 | 66-115 | 3.97-692 | 140-245 | ||||||
| النوع | ضغط العمل | FAD | قوة المحرك | الضوضاء | الوزن ((kg/lbs) | |||||
| بار ((g) | psig | I/s | م3/دقيقة | cfm | كيلوواط | السيارات | dB ((A) | (ب) | FF | |
| المبرد بالماء | ||||||||||
| AQ15VSD W | 4 | 58 | 22-50 | 1.29-302 | 46-107 | 15 | 20 | 64 | 542/1195 | 592/1305 |
| 7 | 102 | 22-46 | 1.34-278 | 47-98 | ||||||
| 10 | 145 | 23-38 | 1.35-229 | 48-81 | ||||||
| 11 | 160 | 23-36 | 1.38-216 | 49-76 | ||||||
| 12.75 | 185 | 22-30 | 1.30-181 | 46-64 | ||||||
| AQ18VSD W | 4 | 58 | 22-62 | 1.29-374 | 46-132 | 18 | 25 | 66 | 542/1195 | 592/1305 |
| 7 | 102 | 22-54 | 1.34-322 | 47-114 | ||||||
| 10 | 145 | 23-45 | 1.35-268 | 48-95 | ||||||
| 11 | 160 | 18-35 | 1.08-2.10 | 38-74 | ||||||
| 12.75 | 185 | 22-37 | 1.30-219 | 46-77 | ||||||
| AQ22VSD W | 4 | 58 | 21-67 | 1.28-403 | 45-142 | 22 | 30 | 67 | 632/1393 | 692/1526 |
| 7 | 102 | 23-65 | 1.35-395 | 48-139 | ||||||
| 10 | 145 | 23-55 | 1.36-331 | 48-117 | ||||||
| 11 | 160 | 22-52 | 1.32-312 | 47-110 | ||||||
| 12.75 | 185 | 22-46 | 1.32-277 | 47-98 | ||||||
| AQ30VSD W | 4 | 58 | 21-82 | 1.28-491 | 45-173 | 30 | 40 | 69 | 632/1393 | 702/1548 |
| 7 | 102 | 23-83 | 1.35-499 | 48-176 | ||||||
| 10 | 145 | 23-78 | 1.36-466 | 48-165 | ||||||
| 11 | 160 | 23-77 | 1.38-462 | 49-163 | ||||||
| 12.75 | 185 | 22-66 | 1.32-398 | 47-140 | ||||||
| AQ37VSD W | 4 | 58 | 45-113 | 2.69-677 | 95-239 | 37 | 50 | 66 | 1186/2614 | 1296/2857 |
| 7 | 102 | 42-110 | 2.51-661 | 89-233 | ||||||
| 10 | 145 | 54-93 | 3.23-556 | 114-196 | ||||||
| 11 | 160 | 60-87 | 3.59-524 | 127-185 | ||||||
| 12.75 | 185 | 69-78 | 4.12-470 | 146-166 | ||||||
| AQ45VSD W | 4 | 58 | 45-135 | 2.69-809 | 95-286 | 45 | 60 | 69 | 1186/2514 | 1296/2857 |
| 7 | 102 | 42-132 | 2.51-7.94 | 89 - 281 | ||||||
| 10 | 145 | 54-108 | 3.23-646 | 114-228 | ||||||
| 11 | 160 | 59-104 | 3.55-622 | 126-220 | ||||||
| 12.75 | 185 | 69-93 | 4.12-556 | 146-196 | ||||||
| AQ55VSD W | 4 | 58 | 45-160 | 2.69-9.60 | 95-339 | 55 | 75 | 72 | 1186/2614 | 1296/2857 |
| 7 | 102 | 42-158 | 2.51-9.50 | 89-335 | ||||||
| 10 | 145 | 54-140 | 3.23-842 | 114-298 | ||||||
| 11 | 160 | 59-133 | 3.56-800 | 126-283 | ||||||
| 12.75 | 185 | 69-120 | 4.12-722 | 146-255 | ||||||
الأبعاد
| النوع | مبردة بالهواء | المبرد بالماء | ||||
| L ((ملم) | و ((م) | ه ((م) | L ((ملم) | و ((م) | ه ((م) | |
| AQ 15-30VSD | 1966 | 974 | 1500 | 1966 | 974 | 1500 |
| AQ 37-55VSD | 2435 | 965 | 1839 | 2435 | 965 | 1839 |
